Fabricated corner piles fc α mc α α α 4 101 6 mm 4 101 6 mm length of t and angle varies female or male corner t pile pz astm yield strength ksi mpa a.
Pz27 sheet pile cad. Scz skz cold formed steel sheet pile delivery conditions tolerances maximum rolled lengths scz skz 90 feet 27 4 m longer lengths may be possible upon request. Sheet piling cad files. Besides our technical department can help you optimize the layout of a sheet pile wall. Pz27 hot rolled sheet piles visit our website section product shape section moment of width height thickness weight weight coating coating description group modulus inertia flange web single 2 sides area in3 ft in4 ft inch inch inch inch lbs ft lbs ft2 ft2 ft ft2 ft cm3 m cm4 m mm mm mm mm kg m kg m2 m2 m m2 m pz27 hot rolled sheet piles z 30 2 184 2 18 00 12 00 0 375 0 375 40 5 27 00 4 48 1.
Piling connector cad files. Pz ps hot rolled steel sheet pile available steel grades astm pz ps yield strength interlock strength ksi mpa ksi mpa k in kn m a 328 39 270 39 270 16 2800 a 572 grade 50 50 345 50 345 20 3500 a 572 grade 60 60 415 a 588 50 345 50 345 20 3500 a 690 50 345 50 345 20 3500 corner and junction piles delivery conditions tolerances astm a 6 mass 2 5 length 5 inches 0. Z shaped sheet piles are called zs because the single piles are shaped roughly like a horizontally stretched z. Pz sheet piles feature mechanical ball and socket connections that allow each steel sheet to interlock with another and create a rigid barrier for earth and water while resisting the lateral pressures of these forces.
Cf 90 cad file flat cross ab cad file cf junction cad file l8 larssen z cad file flat 35ab cad file l90 larssen z cad file tube 180 200 cad file flat 90ab cad file lt pile cad file tube larssen 180 cad. The pzc z profile is the optimal. Pz hot rolled steel sheet pile delivery conditions tolerances astm a 6 mass 2 5 length 5 inches 0 inches interlock combinations maximum rolled lengths pz 105 0 feet 32 0 m longer lengths may be possible upon request. Over the years pz 22 and pz.
The standard sheet piles are saved in a file as a single pile file name contains s or as a double pile file name contains d. Feel free to contact us if you have any question about the files or an issue using them. Z profiles with their optimum distribution of material are the most efficient sheet piling sections available for bending strength. Z piles are the most common type of sheet pile in north america and can be used in a wide variety of applications.
The interlocks are located as far away from the neutral axis as possible to ensure good shear transmission and increase the strength to weight ratio. Made from 100 scrap and is 100 recycable. H pile range from 8 18 piles. In autocad you can import them as a block dwg files only.
Corner piles astm a6 en 10249 2 mass 2 5 7 length 5 inches 0 inches 50 mm straightness bending s 0 25 of the length curving c 0 25 of the length twisting v 2 of the length b2 corner pile b3 corner pile 5. Zz hot rolled sheet pile series download. Hoesch larssen z piles download. The ball and socket interlock also permits flexibility in setting while remaining very durable under driving conditions compared to other systems.
