Pz27 Sheet Pile Section Modulus

A Designer S Introduction To The Development Design And Application

Z profiles with their optimum distribution of material are the most efficient sheet piling sections available for bending strength.

Pz27 sheet pile section modulus. When the pz 27 section was introduced in the 1940 s its section modulus of 30 2 in3 ft was almost three times that published for the arch section with the identical weight per square foot of wall. The allowable stress of the material is a function of the material itself. The steel sheet pile per foot wall is available only if the check vertical balance check box is enabled in the model window section 4 1 1. Smin minimum section modulus.

Steel sheet pile applications are typically designed to create a rigid barrier for earth and water while resisting the lateral pressures of those bending forces. Both the allowable bending moment and the section modulus are specified as per lineal foot or meter of wall. Pzc sheet piling properties 12 56 319 mm 27 88 708 mm 0 375 9 5 mm 0 375 9 5 mm 0 375 9 5 mm pzc 13 27 88 17 7 0 60 0 60 0 525 15 2 mm 13 3 mm 708 mm 450 mm 15 2 mm pzc 26 pzc 39 0 60 15 2 mm. Pz hot rolled steel sheet pile section width w in mm height h in mm thickness cross sectional area in2 ft cm2 m weight section modulus moment of inertia in4 ft cm4 m coating area flange tf in mm web tw in mm pile lb ft kg m wall lb ft2 kg m2 elastic in3 ft cm3 m plastic in3 ft cm3 m both sides ft2 ft of single m2 m wall surface ft2 ft2 m2 m2 pz 22 22 0 559 9 0 229 0 375 9 50 0 375 9.

The pzc z profile is the optimal. These mechanical connections interlock with one another to form a continuous wall of sheet piling. The steel sheet pile should be 50 grade steel and the minimum section modulus is 13 6 cubic inches per foot. For example pzc 18 has a section modulus of 1 800 cm3 meter.

210 vi neh august 2007 ts14r 31. Pz sheet piles feature mechanical ball and socket connections that allow each steel sheet to interlock with another and create a rigid barrier for earth and water while resisting the lateral pressures of these forces. Pz27 hot rolled sheet piles visit our website section product shape section moment of width height thickness weight weight coating coating description group modulus inertia flange web single 2 sides area in3 ft in4 ft inch inch inch inch lbs ft lbs ft2 ft2 ft ft2 ft cm3 m cm4 m mm mm mm mm kg m kg m2 m2 m m2 m pz27 hot rolled sheet piles z 30 2 184 2 18 00 12 00 0 375 0 375 40 5 27 00 4 48 1. Steel sheet piling is a manufactured construction product with a mechanical connection interlock at both ends of the section.

The ball and socket interlock also permits flexibility in setting while remaining very durable under driving conditions compared to other systems. With the interlocks located on the outer fibers of the wall rather than at the center line as is the case with arch or u profile sheet piling sections the wall designer is assured of the published section modulus. Make pzc sheet piling your first choice for its unmatched combination of drivability ruggedness and strength to weight efficiency.
